  4. Artis 170

Artis

Please choose your desired product.

Technical Data

General Data

Welding current min.3 A
Welding current max.170 A
Number of phases 1
Welding current / Duty cycle [10min/40°C]170 A / 40 %
Welding current / Duty cycle [10min/40°C]155 A / 60 %
Welding current / Duty cycle [10min/40°C]140 A / 100 %
Dimension / length435 mm
Dimension / width160 mm
Dimension / height310 mm
Weight9,7 kg
Degree of protectionIP23

Contact

Would you like to find out more about the product?

Send us a message
Find contacts worldwide
Find out more about the features of the Artis welding machine.
Find out more
Current firmware and software updates for the Artis.
Download here

Interactive Operating Instructions

Clear, digital, and mobile—optimized for every end device

Warranty activation

Activate your warranty for free and without obligation
Thumbnail HowTo Artis
1 / 2
How-to video for the Artis product family
HowTo | Set up Artis 300

Function overview

  Artis 170 Artis 210  Artis 300
TAC function x x  x
TIG Pulse x x  x
Touch HF ignition x x  x
HF ignition x x  x
TIG Comfort Stop x x  x
Spot and stitch welding x x  x
MMA and Cel welding x x  x
MMA Pulse x x  x
Anti-stick function x x  x
HotStart function x x  x
TrackingArc x x  x
Generator-compatible x x  x
Adjustable time shutdown/standby mode x x  x
XT version x  x  x
Extended XT functionality - -  x
